Passive Inward Opening Window System

GU05-PA1
Includes screen
Passive performance
Hidden straight-out
Built-in slot


Performance data PERFORMANCE (national inspection report available) Watertight performance National standard level 6 (national standard highest level 6) Airtight performance National standard level 8 (national standard highest level 8) Wind resistance National standard level 9 (national standard highest level 9) Sound insulation performance 30 -42dB (depending on glass configuration) Thermal insulation performance ≤1.0W/m²k (passive window index) Anti-theft coefficient high Profile configuration Ultra-high-precision 6060-T66 aluminum, profile wall thickness 1.8mm Surface treatment Soft White/Dark Night Green/Volcano Brown/Mineral Gray/Starry Black/Matte Black/Morandi Gray/Starry Gray/Roman Silver Brown/Paris Silver Gray Energy-saving configuration National standard PA66 grille multi-cavity insulation strip; frame insulation strip: 45mm, fan insulation strip: 30mm Sealing Configuration EPDM building sealant strips for the entire window (including inner and outer glass sealant strips, fixed window water retaining strips); two-component sealant for the entire window corners Hardware Configuration SIEGENIA + German HOPPE/configurable Yale electric hardware Visible surface Frame 31mm/Middle 31mm/Opening 49mm Glass Configuration 5G(Low-E)+16Ar+5G(warm edge strip, Low-E glass, argon filled, Xinyi/Taiwan Glass original glass)

Get the latest price? We will respond as soon as possible (within 12 hours)

Performance data PERFORMANCE (national inspection report available)
Watertight performance	National standard level 6 (national standard highest level 6)
Airtight performance	National standard level 8 (national standard highest level 8)
Wind resistance	National standard level 9 (national standard highest level 9)
Sound insulation performance	30 -42dB (depending on glass configuration)
Thermal insulation performance	≤1.0W/m²k (passive window index)
Anti-theft coefficient	high
Profile configuration	Ultra-high-precision 6060-T66 aluminum, profile wall thickness 1.8mm
Surface treatment	Soft White/Dark Night Green/Volcano Brown/Mineral Gray/Starry Black/Matte Black/Morandi Gray/Starry Gray/Roman Silver Brown/Paris Silver Gray
Energy-saving configuration	National standard PA66 grille multi-cavity insulation strip; frame insulation strip: 45mm, fan insulation strip: 30mm
Sealing Configuration	EPDM building sealant strips for the entire window (including inner and outer glass sealant strips, fixed window water retaining strips); two-component sealant for the entire window corners
Hardware Configuration	SIEGENIA + German HOPPE/configurable Yale electric hardware
Visible surface	Frame 31mm/Middle 31mm/Opening 49mm
Glass Configuration	5G(Low-E)+16Ar+5G(warm edge strip, Low-E glass, argon filled, Xinyi/Taiwan Glass original glass)
